DP IB Biology: HL

Topic Questions

Home / IB / Biology: HL / DP / Topic Questions / 10. Genetics & Evolution (HL Only) / 10.1 Meiosis / Structured Questions: Paper 2


10.1 Meiosis

Question 1a

Marks: 3
a)
The graph below shows changes in the mass of DNA over the course of a cell cycle.

meiosis-mass-of-dna-graph-sq

Explain the role of the process, represented by this graph, in living organisms.

[3 marks]

    Assess your score


    Question 1b

    Marks: 3
    b)

    Annotate the graph in part a) to show the approximate points at which the following events are taking place:

    i)

    G2

    [1 mark]

    ii)

    Cytokinesis I

    [1 mark]

    iii)

    Metaphase II

    [1 mark]

      Assess your score

      Key Concepts
      Interphase
      Meiosis I

      Question 1c

      Marks: 2
      c)

      Variation is introduced at the points labelled X and Y in the graph in part a).

      Identify processes that could introduce variation at points X and Y.

      [2 marks]

        Assess your score

        Key Concepts
        Causes of Variation

        Question 2a

        Marks: 1
        a)

        The diagram below illustrates the life cycle of the pea aphid, Acyrthosiphon pisum. Note that the term autosome refers to any chromosome that is not a sex chromosome.

        aphid-life-cycle-sq

        Identify the biological sex of the individuals labelled P and Q.

        [1 mark]

          Assess your score

          Key Concepts
          Sex Determination

          Question 2b

          Marks: 4
          b)

          The diagram in part a) shows that aphids use a different type of reproduction in the spring and summer to the type used in the autumn.

          i)

          Identify the type of reproduction used by aphids in the spring and summer, and in the autumn.

          [1 mark]

          ii)

          Explain your answer to part i).

          [2 marks]

          iii)

          Suggest the advantage to the aphids of switching their method of reproduction in the autumn.

          [1 mark]

            Assess your score

            Key Concepts
            Sexual Life Cycle

            Question 2c

            Marks: 2
            c)

            Most eukaryotic chromosomes are described as being monocentric. Aphids have unusual chromosomes known as holocentric chromosomes. A holocentric chromosome after DNA replication is shown in the diagram below.

            chromosome-structure-aphid-holocentric-sq

            Contrast holocentric chromosomes with normal monocentric chromosomes.

            [2 marks]

              Assess your score

              Key Concepts
              Eukaryotic Chromosomes

              Question 2d

              Marks: 4
              d)

              While scientific understanding of aphid meiosis is still limited, the holocentric nature of their chromosomes means that aphids are thought to carry out a form of meiosis known as inverted meiosis. The possible behaviour of a homologous pair of aphid chromosomes during metaphase I is shown in the diagram below.

              -iDx-gkr_inverted-meiosis-homologous-pairs-crossing-over-sq

              Suggest, with reasons, two ways in which meiosis in aphids could be different to conventional meiosis.

              [4 marks]

                Assess your score

                Key Concepts
                Meiosis I
                Meiosis II

                Question 3a

                Marks: 3
                a)

                The spider mite Eutetranychus africanus has very few chromosomes (2n = 4).

                The diagram below shows a series of cells undergoing cell division.

                q3d_10-1_meiosis_medium_ib_hl_biology_sq

                Identify, with reasons, which of the cells in the diagram above belong to E. africanus.

                [3 marks]

                  Assess your score

                  Key Concepts
                  The Process of Meiosis

                  Question 3b

                  Marks: 3
                  b)

                  A sample of cells was taken from the reproductive organs of E. africanus and the mass of DNA in each cell was determined. Some of the cells’ DNA had a mass of 1.7 arbitrary units (a.u.) whilst other cells' DNA had a mass of 3.4 or 6.8 a.u..

                  Use your knowledge of the cell cycle to explain this observation.

                  [3 marks]

                    Assess your score


                    Question 3c

                    Marks: 3
                    c)

                    A species of false spider mite, Brevipalpus phoenicis, is the only animal to have so far been identified as having exclusively haploid cells throughout its life cycle. B. phoenicis populations are entirely female, producing eggs which hatch into more females.

                    The discovery of the haploid nature of B. phoenicis was a surprise to scientists, who believed that being diploid was essential due to the evolutionary advantage that it provides.

                    i)

                    Identify the type of cell division by which B. pheonicis produces eggs.

                    [1 mark]

                    ii)

                    Suggest why scientists might think that diploidy provides an evolutionary advantage.

                    [1 mark]

                    iii)

                    B. phoenicis is a highly successful pest of citrus, tea, and palm plantations. Suggest how B. phoenicis might have evolved to become such a successful pest despite the points covered in parts i) and ii) above.

                    [1 mark]

                      Assess your score


                      Question 3d

                      Marks: 3
                      d)

                      While studying the cells of B. phoenicis scientists discovered that the cells of all individuals contained bacteria. Treatment with antibiotics caused female B. phoenicis to lay eggs that hatched into haploid males.

                      i)

                      Suggest the experimental measure that the scientists would need to take in order to demonstrate that the link between antibiotic treatment and male egg development is causal.

                      [1 mark]

                      ii)
                      Suggest why treatment with antibiotics might have enabled the production of male offspring.

                      [2 marks]

                        Assess your score

                        Key Concepts
                        SRY Gene
                        Antibiotics

                        Question 4a

                        Marks: 3
                        a)

                        The diagram below shows three cells in different stages of cell division. Note that all of the cells shown have the same 2n chromosome number.

                        gene-loci-drosophila-mendelian-ratios-crossing-over-sq

                        Identify the cell(s) in the diagram above that show the following:

                        i)

                        Homologous chromosomes

                        [1 mark]

                        ii)

                        Meiosis

                        [1 mark]

                        iii)

                        Reduction division

                        [1 mark]

                          Assess your score

                          Key Concepts
                          Meiosis I
                          Meiosis II

                          Question 4b

                          Marks: 2
                          b)

                          Fruit flies, Drosophila melanogaster, are frequently used in scientific studies. The diagram below shows the gene loci and alleles of two genes on a pair of chromosomes in a male and female D. melanogaster individual. Note that the dominant alleles are long legs and red eyes.

                          314f7eef-f727-43d6-b876-d08e09ce2d77

                          A cross was carried out between the two individuals shown above. The table below shows the number of offspring with short/long legs and brown/red eyes produced from the cross.

                          Characteristics Number of offspring
                          Short legs and brown eyes 545
                          Long legs and red eyes 182
                          Short legs and red eyes 14
                          Long legs and brown eyes 12

                          Calculate the offspring ratios for the cross shown. Give your answers to the nearest whole number.

                            Assess your score


                            Question 4c

                            Marks: 3
                            c)
                            Explain the offspring ratios shown in part b).

                            [3 marks]

                              Assess your score


                              Question 4d

                              Marks: 2
                              d)

                              The diagram below shows the gene loci and alleles for a third gene on the chromosomes of the individuals in part b). Note that the grey body allele is dominant to the black body allele.

                              7c6274ff-8092-4386-b9a9-054d31f59e1a

                              Suggest, with a reason, how the numbers of offspring with short/long legs and black/grey bodies would differ from the numbers with short/long legs and brown/red eyes shown in part b).

                              [2 marks]

                                Assess your score


                                Question 5a

                                Marks: 8

                                One mark is available for clarity of communication throughout this question.

                                a)

                                Compare and contrast meiosis I and meiosis II.

                                [8 marks]

                                  Assess your score

                                  Key Concepts
                                  Meiosis I
                                  Meiosis II

                                  Question 5b

                                  Marks: 6
                                  b)

                                  Use named examples to describe the roles of mitosis and meiosis in living organisms.

                                  [6 marks]

                                    Assess your score
