11.2 Power Generation & Transmission

Question 1a

Marks: 4

A generator in a hydroelectric plant features a coil rotating in a magnetic field with a constant angular velocity.

exam-style-questions-_-s-cool-the-revision-website

The power output varies over time for a generator rotating with a maximum power output of P0 and a frequency of 20 Hz.

(a)

(i)
Sketch the variation of power output with time for a single complete revolution of the coil. Indicate any key values on your axes.

powergraph [2]

(ii)
Sketch the variation of voltage with time for a single complete revolution of the coil. Indicate any key values on your axes.

RgPOvFTM_11-2-voltage

[2]

    Assess your score


    Question 1b

    Marks: 4
    (b)
    Using Faraday's Law, show that the new power output is 16P0 if the frequency of the rotation of the coil increases to 80 Hz.

    You may use the following equation fraction numerator d ϕ over denominator d t end fraction space equals space minus omega B A space sin space omega t
    [4]
      Assess your score


      Question 1c

      Marks: 2

      A graph showing the variation in power over time for a different hydroelectric generator is shown below.

      JfJrry1g_power-graph-part-c

      In this generator, when the rate of flow of water from the dam doubles, the frequency of revolution of the coil also doubles.

      (c)
      On the diagram above, sketch a curve showing the new variation in power over time when the flow rate halves.
      [2]
        Assess your score


        Question 2a

        Marks: 4

        Bicycles can be fitted with a type of light powered by a dynamo in which a coil of wires is rotated by the motion of the pedals. A dynamo outputs direct current by using a split-ring commutator.

        Before the split-ring commutator is fitted to the generator, it is tested by the manufacturer at a particular frequency. The variation in the current of the AC generator at a particular frequency is given by

        I space equals space I subscript 0 space sin space open parentheses fraction numerator 200 straight pi over denominator 3 end fraction t close parentheses

        The rms value of the alternating current is 2.12 A.

        (a)
        Sketch a graph to show the variation of current against time

        (i)
        For the manufacturer's test.
        [2]
        (ii)
        When the split-ring commutator is fitted to the generator.
        [2]
        For each graph, label the peak current, I0, with a numerical value.
          Assess your score


          Question 2b

          Marks: 3

          For another bike light which only operates on direct potential difference, it is not possible to fit a split-ring commutator to the generator.

          (b)
          Suggest an alternative configuration for supplying the light with direct potential difference from an AC generator, such that the light shines continuously. Explain your reasoning.
          [3]
            Assess your score


            Question 2c

            Marks: 4

            Some bicycle lights rapidly flash off and on at a constant rate to make the cyclist more visible on the road.

            (c)
            Describe and explain the configuration which would lead to this discontinuous flashing effect. You may sketch a graph to aid your explanation.
            [4]
              Assess your score


              Question 3a

              Marks: 3

              Root mean square (rms) values are used throughout this question.

              A step down transformer connects an AC supply to a 18V system of 8 light up garden gnomes connected in parallel. The AC supply has a potential difference of 230V. Each gnome is rated at 35 W at average brightness.

              a)
              Calculate the current in the primary coil of the transformer. Assume that the transformer is ideal.
              [3]

                Assess your score


                Question 3b

                Marks: 4
                (b)
                Flux leakage is one reason why a transformer may not be ideal.

                (i)
                Explain the effect of flux leakage on the transformer.
                [2]
                (ii)
                Discuss a potential change to the transformer that could reduce flux leakage.
                [2]
                  Assess your score


                  Question 3c

                  Marks: 4

                  Transformers are also used to supply electricity to homes with minimal power loss. A power company are evaluating a step-up transformer between a generator in a power plant and power cables leading to homes.

                  The primary coil has 300 turns and the secondary coil has 6000 turns and the cables in the primary and secondary coils have the same resistance.

                  (c)
                  Assuming the transformer is ideal, calculate the power loss in the secondary coil as a percentage of the power loss in the primary coil.
                  [4]
                    Assess your score


                    Question 4a

                    Marks: 2

                    In a nuclear plant, steam heated by fission chain reactions rotates a turbine. This turbine then spins a generator, which is specified as "240 Vrms, 50 Hz AC". The generator produces an rms current of 6.00 A.

                    An ideal transformer steps up the voltage to 2700 Vrms, in preparation for long-distance transfer through an aluminium power line with a resistivity of 2.65 × 10−8 Ω m.

                    (a)
                    Sketch two waveforms of the supply voltage on the same axes, one before and one after the transformer. Include numerical values on the axes where appropriate.
                    [2]
                      Assess your score


                      Question 4b

                      Marks: 6

                      In reality, transformers are not ideal and some power is lost.

                      (b)

                      (i)
                      Explain the mechanism behind the power loss during the transformer's operation.
                      [3]
                      (ii)
                      Assuming 10% of the power is lost, sketch a graph of the variation in power over time in the secondary coil. Include numerical values on the axes where appropriate.
                      [3]
                        Assess your score


                        Question 4c

                        Marks: 4
                        (c)
                        Calculate the power lost over 5 km of the power cable which has a radius of 4 cm.
                        [3]

                          Assess your score


                          Question 4d

                          Marks: 5

                          This cable connects to a step-down generator. The secondary coil supplies power to a flood lamp lighting an important game of ultimate frisbee. It is crucial that the lights do not flicker, but they have been fitted with a single diode.

                          (d)
                          The lamps have been fitted with a single diode as they only operate with direct current:



                          (i)
                          Explain why the lights would flicker with a single diode in the circuit.
                          [2]
                          (ii)
                          Describe a configuration that could be added between the diode and the lamp that would ensure the lights produce a steady beam.
                          [1]
                          (iii)
                          Explain how this configuration produces this effect.
                          [2]
                            Assess your score


                            Question 5a

                            Marks: 4

                            A step-up transformer has a peak current of 1.70 A and 500 turns in its primary coil and 1200 turns on the secondary coil.

                            (a)
                            Calculate the value of the rms current output by the secondary coil for an 80% efficient transformer.
                            [4]
                              Assess your score


                              Question 5b

                              Marks: 3

                              A step-down generator on the other side of the cable brings the rms value of the alternating voltage to 230 V. This is supplied to the main electricity plugs inside a local library. A student charges their laptop.

                              (b)
                              Outline how, and explain why, the alternating current from the mains source must be altered before it can charge a device.
                              [3]

                                Assess your score


                                Question 5c

                                Marks: 4

                                The expression V space equals space 565 space 000 space sin space open parentheses 100 straight pi t close parentheses represents the sinusoidal alternating voltage for an overhead cable on an electrical distribution system

                                (c)

                                (i)
                                Determine the value of the rms voltage.
                                [1]
                                (ii)
                                Explain why such a high voltage is advantageous for the transmission of electrical energy.
                                [3]
                                  Assess your score
